Tapered Roller Bearings — SKF 30200/32200/33200 Series — SKF pneumatic product available at Shri Narayan Machinery LLP Noida
SKF

Tapered Roller Bearings — SKF 30200/32200/33200 Series

SKF Tapered Roller Bearings in the 30200, 32200, and 33200 series are engineered to carry heavy combined radial and axial loads simultaneously. The tapered geometry of the rollers and raceways means these bearings can handle thrust forces that would damage other roller bearing types, making them essential in automotive differentials, wheel hubs, gearbox pinion shafts, and crane slewing drives. SKF's precision manufacturing ensures optimal roller-to-raceway contact across the full roller length, maximizing load distribution and fatigue life. The separable design — with removable cone (inner ring + rollers) and cup (outer ring) — simplifies mounting on shafts and in housings. Adjustable clearance or preload during assembly allows fine-tuning for rigidity or free rotation. Shri Narayan Machinery LLP supplies SKF tapered roller bearings from our Noida warehouse for industrial, automotive, and agricultural applications across Delhi NCR.

Request QuoteCall +91-9811104037
Type: Single Row Tapered RollerSeries Available: 30200, 32200, 33200Bore Size Range: 15mm to 170mmOuter Diameter Range: 35mm to 310mm

Key Features

Designed for combined heavy radial and axial loads in a single bearing row
Separable cone and cup assembly for straightforward shaft and housing mounting
Adjustable clearance/preload during installation for application-specific tuning
SKF Explorer class with logarithmic roller profile for edge-stress-free contact
30200 series for general duty; 32200 and 33200 for increased load capacity
High axial load capability — up to 60% of dynamic radial rating in thrust
Precision-ground raceways for uniform load distribution across full roller length

Technical Specifications

TypeSingle Row Tapered Roller
Series Available30200, 32200, 33200
Bore Size Range15mm to 170mm
Outer Diameter Range35mm to 310mm
Width Range11mm to 91mm
Dynamic Load Rating (max)Up to 600 kN (33200 series, large sizes)
Static Load Rating (max)Up to 710 kN
Contact Angle10° to 30° depending on series
ClearanceAdjustable during mounting
Cone/CupSeparable — cone (inner) and cup (outer) mount independently
Cage MaterialPressed steel

Applications

The Tapered Roller Bearings is used across a wide range of industrial applications:

  • Automotive differentials and wheel hubs — standard fitment in cars and trucks
  • Gearbox pinion shafts — managing axial thrust from helical and bevel gears
  • Crane slewing rings and hoists — heavy combined loads with shock
  • Agricultural implements — plough discs, harvester drums, rotavator shafts
  • Machine tool spindles — lathe headstock bearings with preload adjustment
  • Conveyor head and tail pulleys — heavy-duty material handling systems
  • Rolling mill pinion stands — transmitting torque under high thrust loads

Industries Served

Automotive & Commercial VehiclesAgriculture & Farm EquipmentCranes & Material HandlingMachine ToolsSteel & Metal ProcessingMining & Quarrying

Need Tapered Roller Bearings? Get the Best Dealer Price

As your SKF dealer, Shri Narayan Machinery LLP offers competitive pricing on the entire Tapered Roller Bearings range. Contact us for availability and your best quote.

Request Quote on WhatsAppCall +91-9811104037

C-101, Sector 9, Noida, Uttar Pradesh 201301 | SKF Dealer

Frequently Asked Questions — Tapered Roller Bearings

SKF tapered roller bearings require clearance adjustment during mounting. For most industrial applications, a slight axial clearance (0.03-0.10mm depending on size) is recommended to allow for thermal expansion during operation. Use a dial indicator to measure end play while tightening the lock nut. SKF provides detailed mounting instructions and clearance tables in their technical handbook. Contact Shri Narayan Machinery LLP for guidance specific to your application.
