Thrust Ball Bearings — SKF 51100/51200/51300 Series — SKF pneumatic product available at Shri Narayan Machinery LLP Noida
SKF

Thrust Ball Bearings — SKF 51100/51200/51300 Series

SKF Thrust Ball Bearings in the 51100, 51200, and 51300 series are purpose-built to carry pure axial loads in one direction at moderate speeds. Their flat washer-like profile with a ball complement sandwiched between a shaft washer and a housing washer makes them the simplest and most cost-effective solution for axial load support. Available in single-direction (511) and double-direction (522/523) configurations, these bearings are widely used in crane hooks, screw jacks, turntables, indexing tables, and vertical shaft arrangements. SKF's precision-ground raceways ensure smooth rotation even under heavy thrust, while the pressed steel cage maintains uniform ball spacing for quiet, vibration-free operation. The 51300 series offers higher load ratings than the 51100 and 51200 for demanding applications. Shri Narayan Machinery LLP in Noida stocks SKF thrust ball bearings for immediate delivery to industries across Delhi NCR, Greater Noida, and Ghaziabad.

Request QuoteCall +91-9811104037
Type: Single/Double Direction Thrust BallSeries Available: 51100, 51200, 51300 (single); 52200, 52300 (double)Bore Size Range: 10mm to 150mm (shaft washer ID)Outer Diameter Range: 24mm to 250mm (housing washer OD)

Key Features

Purpose-designed for pure axial (thrust) loads — does not handle radial loads
Single-direction (511) and double-direction (522/523) variants available
Simple flat washer construction for easy installation in vertical shaft arrangements
Pressed steel cage ensures uniform ball spacing and smooth, quiet operation
51300 series provides higher load capacity with wider cross-section
Self-aligning seat washers available to compensate for housing misalignment
Low profile — minimal axial space required compared to other thrust bearing types

Technical Specifications

TypeSingle/Double Direction Thrust Ball
Series Available51100, 51200, 51300 (single); 52200, 52300 (double)
Bore Size Range10mm to 150mm (shaft washer ID)
Outer Diameter Range24mm to 250mm (housing washer OD)
Height Range9mm to 60mm
Dynamic Load Rating (max)Up to 160 kN (51300 series)
Static Load Rating (max)Up to 500 kN (51300 series)
Limiting SpeedUp to 6,000 RPM (small bores, 51100 series)
Cage MaterialPressed steel
Load DirectionAxial only (one direction or both, depending on type)

Applications

The Thrust Ball Bearings is used across a wide range of industrial applications:

  • Crane hooks and swivels — supporting vertical loads with free rotation
  • Screw jacks and lifting devices — thrust loads from lead screw mechanisms
  • Turntables and indexing tables — smooth axial rotation under heavy platens
  • Vertical pump shafts — supporting rotor weight in vertical motor-pump sets
  • Machine tool tailstocks — axial load from live center pressure
  • Automotive clutch release bearings — thrust during engagement/disengagement

Industries Served

Cranes & Hoisting EquipmentMachine ToolsPumps & Vertical Shaft MachineryAutomotive & Commercial Vehicles

Need Thrust Ball Bearings? Get the Best Dealer Price

As your SKF dealer, Shri Narayan Machinery LLP offers competitive pricing on the entire Thrust Ball Bearings range. Contact us for availability and your best quote.

Request Quote on WhatsAppCall +91-9811104037

C-101, Sector 9, Noida, Uttar Pradesh 201301 | SKF Dealer

Frequently Asked Questions — Thrust Ball Bearings

No. Thrust ball bearings are designed exclusively for axial (thrust) loads. They cannot handle any radial load. In most applications, a thrust ball bearing is used alongside a radial bearing (such as a deep groove ball bearing) that supports the radial forces. Applying radial load to a thrust bearing will cause rapid failure.
