Pneumatic Directional Control Valves
SPAC manufactures a comprehensive range of pneumatic directional control valves essential for controlling the movement of pneumatic cylinders. The lineup includes solenoid-operated valves (electrically actuated via PLC or manual switch), manually operated valves (hand lever and push button), and foot pedal valves. Available in 5/2 way (for double-acting cylinders), 5/3 way (with center position options), 3/2 way (for single-acting cylinders), and 2/2 way (on/off) configurations. Port sizes from 1/8 inch to 1 inch cover everything from compact automation to heavy industrial pneumatic systems.
Key Features
Technical Specifications
| Valve Types | 5/2, 5/3, 3/2, 2/2 Way |
| Actuation | Solenoid (DC/AC), Manual Lever, Push Button, Foot Pedal |
| Port Sizes | 1/8", 1/4", 3/8", 1/2", 1" |
| Operating Pressure | 1.5–8 kgf/cm² |
Available Models & Variants
FG Series — 5/2 Solenoid Valve
Electrically actuated 5/2 way valve for controlling double-acting cylinders. The most common valve for PLC-controlled automation.
GY Series — 5/2 & 5/3 Solenoid Valve
Available in 5/2 and 5/3 way configurations. The 5/3 way offers a center position (closed, pressurized, or exhausted) for holding or floating the cylinder.
P/TG Series — Hand Lever & Foot Pedal Valve
Manually operated valves for applications where the operator directly controls cylinder movement.
P Series — Mechanical Valve
Mechanically actuated valves triggered by roller levers, plungers, or cams for limit-switching in pneumatic circuits.
Applications
The Control Valves is used across a wide range of industrial applications:
- Controlling double-acting pneumatic cylinders (5/2 way valves)
- PLC-controlled automation systems (solenoid valves)
- Manual machine control (hand lever valves)
- Foot-operated presses and machines (foot pedal valves)
- Emergency stop circuits (3/2 way normally closed)
- Air blow-off and cleaning (2/2 way valves)
Industries Served
Why Buy From Shri Narayan Machinery LLP?
Every pneumatic cylinder needs a valve to control it. SPAC valves are designed to work seamlessly with SPAC cylinders, and we stock the most common configurations for immediate availability.
