Miranda Solid Carbide Jobber Drills — DIN 338, AlTiN Coated, 1mm to 20mm — Miranda (Dormer Pramet) pneumatic product available at Shri Narayan Machinery LLP Noida
Miranda (Dormer Pramet)

Miranda Solid Carbide Jobber Drills — DIN 338, AlTiN Coated, 1mm to 20mm

Your HSS drill wearing out after 50 holes? A Miranda solid carbide jobber drill does 500+ holes at twice the cutting speed — and the hole quality stays consistent from first to last. These DIN 338 drills cover 1.00mm to 20.00mm diameter in 0.10mm increments, giving you exact size coverage for any precision drilling job. The 140-degree point angle centers itself on the workpiece without walking, eliminating the need for a separate centre drill in most materials. AlTiN (Aluminium Titanium Nitride) coating handles temperatures up to 900°C at the cutting edge, so you can run higher speeds without coolant breakdown. The 4xD depth ratio makes these the go-to choice for general-purpose through-hole and blind-hole drilling in steel, stainless steel, cast iron, and aluminium. Available at Shri Narayan Machinery LLP in Noida — request a quote for single drills or full diameter sets.

Request QuoteCall +91-9811104037
Diameter Range: 1.00mm to 20.00mm (0.10mm increments)Depth Capability: 4xD (4 times diameter)Point Angle: 140°Coating: AlTiN (Aluminium Titanium Nitride)

Key Features

DIN 338 standard — universal compatibility with all drill chucks and CNC collets
140° self-centering point angle reduces walking and eliminates pilot hole requirements
AlTiN coating withstands 900°C edge temperatures for 2-3x tool life vs uncoated carbide
4xD depth capability for standard through-hole and blind-hole drilling
Diameter range 1.00mm to 20.00mm in precise 0.10mm increments
h6 shank tolerance for zero-runout performance in hydraulic and shrink-fit holders
Micro-grain carbide substrate for optimal hardness-toughness balance
Two-flute design with polished flutes for efficient chip evacuation

Technical Specifications

Diameter Range1.00mm to 20.00mm (0.10mm increments)
Depth Capability4xD (4 times diameter)
Point Angle140°
CoatingAlTiN (Aluminium Titanium Nitride)
StandardDIN 338
Flutes2
Shank Toleranceh6
SubstrateMicro-grain tungsten carbide
Max Edge Temperature900°C

Applications

The Solid Carbide Jobber Drills is used across a wide range of industrial applications:

  • Precision hole drilling in CNC machining centres and VMCs
  • Production drilling in automotive component manufacturing
  • Through-hole and blind-hole drilling in steel and stainless steel
  • General-purpose drilling in cast iron, aluminium, and non-ferrous metals
  • Batch production drilling where consistent hole quality is critical
  • Tool room and die-making precision drilling operations
  • Replacement for worn HSS drills where higher productivity is needed

Industries Served

Automotive manufacturingGeneral engineering and job shopsAerospace component productionDie and mould makingMedical device manufacturingDefence and ordnance factories

Need Solid Carbide Jobber Drills? Get the Best Dealer Price

As your Miranda (Dormer Pramet) dealer, Shri Narayan Machinery LLP offers competitive pricing on the entire Solid Carbide Jobber Drills range. Contact us for availability and your best quote.

Request Quote on WhatsAppCall +91-9811104037

C-101, Sector 9, Noida, Uttar Pradesh 201301 | Miranda (Dormer Pramet) Dealer

Frequently Asked Questions — Solid Carbide Jobber Drills

In typical steel (HRC 20-30), a Miranda AlTiN-coated carbide jobber drill lasts 5-10 times longer than a standard HSS drill. You can also run at 2-3x the cutting speed, so you get both more holes per drill and faster cycle times. The exact improvement depends on workpiece material, cutting parameters, and coolant — but most shops see payback within the first 100 holes even at the higher per-drill cost.
